| الاسم التجاري: | Mckee Charging Cube |
| رقم الطراز: | CLF-DC 26 كيلو وات في الساعة |
| الـ MOQ: | 1 |
| السعر: | Negotiate |
| تفاصيل التعبئة: | التعبئة والتغليف حالة خشبية |
| شروط الدفع: | د/أ، د/ف، تي/تي، ويسترن يونيون |
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Electric Current | 250A / 600A | Input Voltage | 327V-456Vac |
| Power Range | Complete: 0-2400A
|
Output Voltage | 50V-1000V |
| Protection Rating | IP54 | Input Frequency | 45Hz-65Hz |
| Operating Temp. | -30~85℃
|
Power Factor | ≥0.99 |
| Operating Humidity | 5%-95% (Non-condensing) | Peak Efficiency | ≥95.5% |
| Max. Altitude | ≤2000m | Output Routes | Max 12 (Compatible 6/8/10) |
| Safety Features | Short circuit / Leakage / Overcurrent / Emergency Stop | Material | PC Flame-retardant |
| Interfaces | RFID / Swipe Card / GPRS / RS485 / CAN / Ethernet | Cable Length | 5m / 10m |
| Communication Protocol | OCPP 1.6 | Main Unit Dimensions | 1355 × 995 × 2000 mm |
| Packaging | Wooden Case | Terminal Dimensions | 325 × 450 × 1430 mm |
FAQ
Q: How long is your delivery time?
For charging posts, it is usually 3-10 days. If there is no stock, the production lead time is determined according to the order quantity. High-power DC charging posts usually need to be customized according to the customer's technical parameters.
Q: How long does it take to customize the prototype?
For charging piles, the prototype time is usually 7 days.
For DC charging post, the prototype time is usually 15 days.
For high power fast charging station, the technical parameters need to be determined before production, and the prototype time is usually 30 days.
Q: How to guarantee the service?
Our products are divided into two categories: household and commercial.
For home chargers, we provide standardized service: 1 year warranty + remote installation and usage guidance + video installation tutorial
For commercial chargers, we not only provide standardized services for charging piles, but also provide payment software docking services for operating companies.
Q: How do you guarantee the quality of your products?
The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are in progress.
Q: How do you guarantee the quality of your products?
The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are in progress.
NOTE:
1- OEM supported.
2- Any requirement please contact us to talk about the details.
3- We will reply you for your inquiry in 24 hours.
4- If you have any questions about the charger, please contact us.
5- The above for reference only, final price decide by the charger KW, please contact us to get the correct quote.
